Scientific Division
Expert Line
| Specification | PLW8683 | PLW8683CD |
|---|---|---|
|
Wash cabinet usable capacity |
145 L |
145 L |
|
Circulation pump type |
Variable-speed pump |
Variable-speed pump |
|
Circulation pump, Qmax |
500 L/min |
500 L/min |
|
Maximum final rinse temperature |
93 °C |
93 °C |
|
Factory programmes |
19 programmes |
20 programmes |
|
Free programme positions |
10 programmes |
10 programmes |
|
Control type |
M Touch Flex |
M Touch Flex |
|
Drain pump |
Yes |
Yes |
|
Drying unit |
N/A |
Yes, Max Temp 115°C |
|
Electrical Door lock |
Yes |
Yes |
|
Glass door |
Yes, (Option) |
Yes, (Option) |
|
Electrical connection |
3N AC 400 V 50 Hz |
3N AC 400 V 50 Hz |
|
Dimension (hight x width x depth) |
835 x 598 x 598 mm |
835 x 898 x 700 mm |
| Specification | PLW8683 |
|---|---|
|
Wash cabinet usable capacity |
241 L |
|
Circulation pump type |
Variable-speed pump |
|
Circulation pump, Qmax |
750 L/min |
|
Maximum final rinse temperature |
93 °C |
|
Factory programmes |
23 programmes |
|
Free programme positions |
20 programmes |
|
Printer for process documentation |
Yes, (Option) |
|
Control type |
Touch Control |
|
Drain pump |
Yes |
|
Drying unit |
Yes, Max Temp 115°C |
|
Electrical Door lock |
Yes |
|
Glass door |
Yes |
|
Electrical connection |
3N AC 400 V 50 Hz |
|
Dimension (hight x width x depth) |
1965 x 650 x 702 mm |
| Specification | PLW8615 | PLW8616 |
|---|---|---|
|
Wash cabinet usable capacity |
351 L |
351 L |
|
Circulation pump type |
Variable-speed pump |
Variable-speed pump |
|
Circulation pump, Qmax |
600 L/min |
600 L/min |
|
Maximum final rinse temperature |
93 °C |
93 °C |
|
Factory programmes |
30 programmes |
30 programmes |
|
Free programme positions |
170 programmes |
170 programmes |
|
Printer for process documentation |
Yes, (Option) |
Yes, (Option) |
|
Control type |
PST 20, Full-touch colour display |
PST 20, Full-touch colour display |
|
Drain pump |
Yes |
Yes |
|
Drying unit |
Yes, Max Temp 115°C |
Yes, Max Temp 115°C |
|
Electrical Door lock |
Yes |
Yes |
|
Glass door |
Yes, 1 door |
Yes, 2 door |
|
Electrical connection |
3N AC 400 V 50 Hz |
3N AC 400 V 50 Hz |
|
Dimension (hight x width x depth) |
1670 x 900 x 990 mm |
1670 x 900 x 990 mm |
