Cell Analyzer
| Specification | BioProfile Flex2 |
|---|---|
|
Chemistry Module |
Glucose, Lactate, Glutamine, Glutamate, Ammonium, Sodium, Potassium, Calcium |
|
pH/Gas Module |
pH, PCO2, PO2 |
|
Osmometer Module |
Osmolality, (Optional) |
|
Cell Density/Viability Module |
Total Cell Density, Cell Diameter, Viable Cell Density, %Viability (Optional) |
|
Sample Analysis Time |
4.5 minutes |
|
Sample Volume |
265 µL |
|
Sample Options |
Individual via syringe/cup, Automated 24-position tray, Automated 96-well plates |
|
Automated Auto Sample |
Bioreactors, (Optional)
ambr® 15 and ambr® 250 cell culture system, (Optional) |
|
Automated dilutions |
Yes |
|
Dimension (hight x width x depth) |
Without osmometer module: 610 x 430 x 640 mm With osmometer module: 610 x 640 x 640 mm |
|
Electrical Requirements |
90-264 VAC, 50 to 60 Hz |
|
Certifications |
IEC 61010-1:2010, OPC Compliant, PAT Compatible, 21 CFR Part 11 Compliant |
| Specification | BioProfile Flex2 Basic A |
|---|---|
|
Chemistry Module |
Glucose, Lactate, Glutamine, Glutamate, Ammonium, Sodium, Potassium, Calcium |
|
pH/Gas Module |
pH, PCO2, PO2 |
|
Osmometer Module |
N/A |
|
Cell Density/Viability Module |
N/A |
|
Sample Analysis Time |
2.0 minutes |
|
Sample Volume |
265 µL |
|
Sample Options |
Individual via syringe/cup ,Automated 20-position tray, Automated 96-well plates |
|
Automated Auto Sample |
N/A |
|
Automated dilutions |
Yes |
|
Dimension (hight x width x depth) |
597 x 425 x 635 mm |
|
Electrical Requirements |
90-264 VAC, 50 to 60 Hz |
|
Certifications |
IEC 61010-1:2010, OPC Compliant, PAT Compatible, 21 CFR Part 11 Compliant |
| Specification | BioProfile FastCDV |
|---|---|
|
Cell Density/Viability Module |
Total Cell Density, Cell Diameter, Viable Cell Density, %Viability |
|
Measurement Range |
Cell Density (CD): 50,000 – 140,000,000 cells/mL |
|
|
Viability Range: 0 to 100% |
|
|
Live Cell Diameter Range: 4 to 70 μm |
|
Sample Analysis Time |
85 Secounds |
|
Sample Volume |
100 µL |
|
Sample Options |
Automated 32 carousel tray, Automated 96-well plates |
|
Automated dilutions |
Yes |
|
Dimension (hight x width x depth) |
565 x 445 x 559 mm |
|
Electrical Requirements |
220-240 VAC, 50/60 Hz |
|
Certifications |
IEC 61010-1:2001, OPC Compliant, PAT Compatible, 21 CFR Part 11 Compliant |
