Biological Safety Cabinet (BSC)
| Specification | Bio II Advance Plus 3 | Bio II Advance Plus 4 | Bio II Advance Plus 6 |
|---|---|---|---|
|
External dimensions (WxDxH) |
1049x764x1260 mm |
1354x764x1260 mm |
1964x764x1260 mm |
|
Internal dimensions (WxDxH) |
954x602x580 mm |
1259x602x580 mm |
1869x602x580 mm |
|
Weight |
180 kg |
200 kg |
280 kg |
|
Laminar flow speed |
0.35 m/s |
0.35 m/s |
0.35 m/s |
|
Front entry air speed |
0.55 m/s |
0.55 m/s |
0.5 m/s |
|
Power |
0.125 Kw |
0.125 Kw |
0.338 Kw |
|
Electrical connection |
230V, 50-60 Hz |
230V, 50-60 Hz |
230V, 50-60 Hz |
|
Lighting |
≥ 1000 Lux |
≥ 1000 Lux |
≥ 1000 Lux |
|
Sound |
≤ 58 dBA |
≤ 58 dBA |
≤ 58 dBA |
|
Vibration |
< 0.005 mm RMS |
< 0.005 mm RMS |
< 0.005 mm RMS |
|
Certified Safety |
EN12469 Class II biological safety cabinets (30% exhaust, 70% recirculation unit) |
||
|
Filters |
HEPA H14 filters according to EN 1822: efficiency of 99.995% MPPS and 99.999 % DOP |
||
|
Air Quality |
ISO 4 in accordance with ISO CD 14644-1: 353 part. ≥ 0.5 µm/m3 ; 10000 part. ≥ 0.1 µm/m3 |
||
| Specification | BioIIAdvancePlus Anatomical Pathology (AP) |
|---|---|
|
External dimensions (WxDxH) |
1961x764x2219 mm |
|
Internal dimensions (WxDxH) |
1869x602x580 mm |
|
Weight |
350 kg |
|
Laminar flow speed / laminar flow rate |
0.35 ms |
|
Front entry air speed / extraction flow rate |
0.50 ms |
|
Power |
0.338 kw |
|
Electrical connection |
230V, 50-60 Hz |
|
Lighting |
≥ 1000 Lux |
|
Sound |
≤ 58 dBA |
|
Certified Safety |
EN12469 Class II biological safety cabinets (30% exhaust, 70% recirculation unit) |
|
Filters |
HEPA H14 filters according to EN 1822: efficiency of 99.995% MPPS and 99.999 % DOP |
|
Air Quality |
ISO 4 in accordance with ISO CD 14644-1: 353 part. ≥ 0.5 µm/m3 ; 10000 part. ≥ 0.1 µm/m3 |
| Specification | BiOptima 3 | BiOptima 4 | BiOptima 5 | BiOptima 6 |
|---|---|---|---|---|
|
External dimensions (WxDxH) |
1033x797x1450 mm |
1338x797x1450 mm |
1643x797x1450 mm |
1948x797x1450 mm |
|
Internal dimensions (WxDxH) |
885x548x666 mm |
1190x548x666 mm |
1495x548x666 mm |
1800x548x666 mm |
|
Weight |
190 kg |
220 kg |
250 kg |
285 kg |
|
Laminar flow speed |
0.35 m/s |
0.35 m/s |
0.35 m/s |
0.35 m/s |
|
Front entry air speed |
0.6 m/s |
0.65 m/s |
0.6 m/s |
0.6 m/s |
|
Power |
0.150 Kw |
0.190 Kw |
0.220 Kw |
0.240 Kw |
|
Electrical connection |
230V, 50 Hz |
230V, 50 Hz |
230V, 50 Hz |
230V, 50 Hz |
|
Lighting |
≥ 900 Lux |
≥ 1000 Lux |
≥ 1000 Lux |
≥ 1000 Lux |
|
Sound |
≤ 53 dBA |
≤ 58 dBA |
≤ 58 dBA |
≤ 58 dBA |
|
Vibration |
< 0.005 mm RMS |
< 0.005 mm RMS |
< 0.005 mm RMS |
< 0.005 mm RMS |
|
Electrical sliding front window |
Yes |
Yes |
Yes |
Yes |
|
Pre Filter |
G3 |
G3 |
G3 |
G3 |
|
Certified Safety |
EN12469 Class II biological safety cabinets (30% exhaust, 70% recirculation unit) |
|||
|
Filters |
HEPA H14 filters according to EN 1822: efficiency of 99.995% MPPS and 99.999 % DOP |
|||
|
Air Quality |
ISO 4 in accordance with ISO CD 14644-1: 353 part. ≥ 0.5 µm/m3 ; 10000 part. ≥ 0.1 µm/m3 |
|||
